Plot a Window-Pane Grid — plot_window

Visualizes candidate relative-time windows created by make_windows(). The vertical dashed line marks the reference date. Windows fully before the reference, fully after the reference, and crossing the reference are colored separately so the timing logic is visible.

Usage

plot_window_pane(
  windows,
  max_windows = 30,
  color_by = c("timing", "width", "none"),
  title = "Window-pane grid",
  subtitle = NULL,
  xlab = "Time relative to reference date",
  ylab = "Candidate window",
  reference_label = "Reference date"
)

Arguments

windows: A data frame created by make_windows().
max_windows: Maximum number of windows to display. Use Inf to show all rows.
color_by: Character value controlling segment color. Use "timing" to color windows by position relative to the reference date, "width" to color by window duration, or "none" for one color.
title: Plot title.
subtitle: Plot subtitle. If NULL, a subtitle is generated from the selected color_by value.
xlab: X-axis label.
ylab: Y-axis label.
reference_label: Label used for the vertical line at relative-time 0.

Value

A ggplot2 object.

Examples

windows <- make_windows(min_offset = -14, max_offset = 35, width = 7, slide_by = 7)
plot_window_pane(windows)


variable_windows <- make_windows(min_offset = -21, max_offset = -1, width = c(3, 5, 7))
plot_window_pane(variable_windows, color_by = "width")
